Miter Fence

•

• •The table is equipped with a 45°miter fence, allowing for cutting, boring and moulding operations. Right and left 45°angular tenons can be accomplished at a time.

 Air Clamp

•

• •The workpiece is clamped by air cylinder for convenient and fart clamping and unclamping.

 Variable Workpiece Feed Speed

•

• •The machine employs two speed regulator knobs to adjust the table feed forward and backward speeds. permitting workpiece contacting cutter smoothly.
• •Variable feed speed makes the machine ideal for cutting hard and soft wood

 Moulding Unit

•

• •The moulding units consists of two spindles.
• •One spindle is fixed, while the other spindle can be adjusted in height position.
• •The moulding unit is equipped with a seethru guard to prevent chips from splashing.

 Boring Unit

•

• •The boring unit is driven by a 3 HP motor.
• •One 5-spindles boring head is standard equipment. Other types of boring head are available upon request.
• •The boring unit moves on high precision linear guide ways for smooth trowel and high linear accuracy.
• •Boring head stroke is adjustable.

 Centralized Control Panel

•

• •All motion controls of the machine are completely centralized on a control panel, providing operational convenience for operator.
•  控。

 Electronic Parts Meet European Standards

•

• •The control circuit in the electric cabinet consists of French TE brand electronic components, meeting European standards.
•  The high performance control circuit assure sensitive and stable motion controls at all times. 。
