Model

HS-125 / 3231

HS-135 / 3231

Saw carriage speed

150 M/Min.

160 M/Min. or faster

Main saw motor

20 HP (Opt. 30 HP, 40 HP variable speed )

Scoring saw motor

2 HP

Saw carriage driven motor

1 HP

Gripper unit speed

100 M/Min.

NC panel pusher motor

AC servo motor

Maximum panel width

3,250 mm (Opt. 4,450 mm, 5,650 mm)

Maximum panel length

3,100 mm (Opt. 4,300 mm, 5,500 mm)

Saw blade projection

Programable 0~125 mm

Programable 0~135 mm

Main saw speed

3,850 rpm

Scoring saw speed

7,000 rpm

Compress air required

7~10 Kg /cm2 (100~147 PSI)

Net weight

4,800 kg

Gross weight, pallet only

5,600 kg

Packing dimensions

20 feet container required

verall dimensions

525 × 590 × 170 cm

Model

HS-125L / 3222

HS-135L / 3222

Lifting table size

3.2 M × 2.2 M (Opt. 4.4 M × 2.2 M, 3.2 M × 2.5 M)

Lifting table height

H=0.56 M (Opt. H=1.08 M)

Lifting table load

Payload limited 2,000 kg

Net weight

9,000 Kg

Gross weight, pallet only

10,300 Kg

Packing dimensions

40 feet container required

Overall dimensions

525 × 1,100 × 170 cm
