BLADE ADJUSTMENT MECHANISM
1.Blade guide fixing knob
2.Blade guide raising handwheel
3.Blade track adjustment Knob
4.Blade Tension handwheel
5.Blade tension indicator
|
|
|
|
Blade Guide
Convenient side guide adjustment is made through micrometric adjustment knob for narrow blades. Blade guide mechanism is equipped with bearing, providing rigid back-up support of blade.
|
|
|
|
MITER GAUGE
Manufactured from cast aluminum, this miter gauge is suitable for straight and angle cutting, It probides60 angle adjustment at the right and the left side with easy-to read graduated scale.
|
|
|
|
SAW WHEEL
The saw wheel suits blade widths from1/4” to 2”(50MM)making this machine ideal for curve cutting and rip cutting
The saw wheels are laminated with rubber for accurate blade tracking. Positive grip and maximum blade durability.
|
|
|
The table can tilted 45 front downward by direct hand tilting 4
|
